     2008 270 Chassis Kits



       2008 King 270cc/125cc Deluxe Roller:

       Includes:

  • New 2008 4130 1 1/4" .083 Down Tube Chromoly Paint Ready Chassis
  • New 2008 Fiberglass Two piece hood w/ Scoop
  • 4130 1 3/8" .095 front axle assembly complete
  • 52" splined rear axle assembly w/floater brake complete
  • Torsion suspension complete
  • Swedged aluminum radius rod set w/ F&K rod ends
  • Throttle & brake pedal assemblies
  • Chain tensioner block assembly
  • Complete brake system w/Wilwood CNC Caliper & MCP master cylinder
  • Steering shaft w/13" Sweet steering wheel & quick release
  • 12 Gallon tail tank w/ cap assembly
  • Weld front wheels w/o locks
  • Weld rear wheels w/ RR beadlock
  • Four tires - Hoosier or American Racer
  • 12' Sq. Wing Dynamics wing made to our specs
  • #1 & #2 wing adjuster assembly
  • Kirkey high back off set seat w/upholstrey
  • Bumpers & nerfs
  • Heavy duty shift cable and lever
  • Simpson 5 point belts w/choice of colors
  • Chassis set-up guide w/technical support
  • Roller assembled and set up .........................................................$6995.00



              Options:

  • ARS Gas Charged Shock............................... .................................$275.00ea
  • ARS Gas Adjustable Shock..............................................................$495.00ea
  • Each Additional Weld Beadlock ........................................................$ 89.00ea
  • Radiator w/ Welded 3/4" Barb Fittings ..............................................$275.00
  • 54" Side Boards on Wing ................................................................$ 80.00
  • *Prices subject to change without notice

--------------------------------------------------------------------------------------------------------------------------------------------



        2008– 270 Conversion Kit

          Includes:

  • New 2008 4130 Down Tube Paint Ready Chassis
  • New 2008 Fiberglass Two piece Hood w/ Scoop
  • Complete Set of body panels w/ dzus springs and fasteners
  • Front Axle Tube
  • Direct Steering Shaft w/ welded u-joint
  • Torsion and Steering Bushings
  • Front and Rear torsion Arms
  • Complete Set of Torsion Stops
  • Left and right birdcage assemblies
  • Panhard Bracket
  • W-Link assembly
  • Complete set of bumpers & nerfs
  • Front wing upright w/ Cross Shaft
  • Complete set of Swedged Radius Rods
  • Set up guide
  • Price.........................................................................................$3999.00
  • **Prices subject to change without notice
